The difference of mobile phone packet capture software
Brook and mitmproxy for mobile app deep packet capture
Brook can also capture and modify packets independently without relying on any other software.
Read documentation: https://brook.app
Configure as follows, then connect to Brook
Script:
text := import("text")
f := func(){
if in_dnsquery {
// block secure dns
if in_dnsquery.domain == "dns.google" {
return {block: true}
}
}
if in_address {
m := in_address
if m.ipaddress {
// block secure dns
if m.ipaddress == "8.8.8.8:853" || m.ipaddress == "8.8.8.8:443" || m.ipaddress == "8.8.4.4:853" || m.ipaddress == "8.8.4.4:443" || m.ipaddress == "[2001:4860:4860::8888]:853" || m.ipaddress == "[2001:4860:4860::8888]:443" || m.ipaddress == "[2001:4860:4860::8844]:853" || m.ipaddress == "[2001:4860:4860::8844]:443" {
return { "block": true }
}
// block or bypass udp
if m.network == "udp" {
return { bypass: true } // or { block : true }
}
}
if m.domainaddress {
// block secure dns
if text.has_prefix(m.domainaddress, "dns.google:") {
return { "block": true }
}
// Packet Capture all tcp 80, most http/1.1 use it
if m.network == "tcp" && text.has_suffix(m.domainaddress, ":80"){
return {"mitm": true, "mitmprotocol": "http", "mitmwithbody": true, "mitmautohandlecompress": true}
}
// Packet Capture all tcp 443, most https http/1.1 and http/2 use it
if m.network == "tcp" && text.has_suffix(m.domainaddress, ":443"){
return {"mitm": true, "mitmprotocol": "https", "mitmwithbody": true, "mitmautohandlecompress": true}
}
// block udp on port 443, most http/3 use it
if m.network == "udp" && text.has_suffix(m.domainaddress, ":443"){
return { block: true }
}
}
}
if in_httprequest && !in_httpresponse {
return in_httprequest // or Modify Packet
}
if in_httprequest && in_httpresponse {
delete(in_httpresponse, "Alt-Svc") // Avoid upgrading to http3 from http1 or http2
return in_httpresponse // or Modify Packet
}
}
out := f()
This script assumes that all TCP port 443 is used as https protocol to capture packets, and all TCP port 80 is used as http to capture packets. The script address is here.
Read the documentation https://brook.app
Then open the app you want to capture packets
TODO
